INTERNAL DIMENSIONS (HxWxD) (mm) | 1.340 x 600 x 660 |
 |
EXTERNAL DIMENSIONS (HxWxD) (mm) | 1980 x 730 x 920 |
 |
INTERNAL VOLUME (Liters) | 600 |
 |
TEMPERATURE RANGE (ºC) | 0ºC to 45ºC (upgradable up to 60ºC) |
|
TEMPERATURE UNIFORMITY | +/- 1ºC |
 |
HUMIDITY RANGE | 35 to 95% RH |
|
HUMIDITY UNIFORMITY | +/- 2% RH |
 |
VISIBLE LIGHTS | 26.000 Lux (+/- 6% Approx.) ICH Q1B Visible light test in approximately 46h |
|
UV LIGHTS | 30 W/m² (+/- 10% Approx.) ICH Q1B UV light test in approximately 7h |
|
TEMPERATURE UNIFORMITY (LIGHTS ON) | +/- 2ºC |
|
HUMIDITY UNIFORMITY (LIGHTS ON) | +/- 4% RH |
 |
ICH COMPLIANCE | Photostability Q1B and Q1B part 2 Stability Q1A |
 |
SHELVING / STORAGE (m2) | 1 shelf with Visible lights (0,17m²) 1 shelf with UV lights (0,17m²) - Photostability shelves and light banks can be removed and replaced by multiple wire shelves for Stability testing with a greater storage area - |
 |
ELECTRICAL CONNECTION | 1/N/PE AC 230V +/- 10%; 50Hz |
