| Family | 130 | 530 | 830 | 930 |
|---|---|---|---|---|
| Actuator Type | Electromechanical | Electrodynamic | Electrodynamic | Servohydraulic |
| Test Type | Static | Static, Dynamic, Fatigue | Static, Dynamic, Fatigue | Static, Dynamic, Fatigue |
| Axial Force Ranges | 225 N to 5 kN(50 lbfto 1,125 lbf) | 800 N to 2.5 kN(180lbfto 560lbf) | 2.5 kN to 50 kN(560 lbf to 11,250 lbf) | 100 kN to 500 kN(22,500 lbf to 110 kip) |
| Dynamic Torque Rating | ±10 Nm to 28 Nm(90 lbf·in to 250 lbf·in) | ±6Nm to 20Nm(53 lbf·into 177 lbf·in) | ±10 Nm to 300 Nm(90 lbf·into 2,650lbf·in) | ±1 Nm to 2 kNm(9 lbf·into 17,700lbf·in) |
| Max Frequency | 2 Hz | 15 Hz | 15 Hz | 20 Hz |
| Model | 130LA1 | 130LA2 | 130LA3 |
|---|---|---|---|
| Type | Electromechanical | Electromechanical | Electromechanical |
| Max Axial Force | ±222 N (50 lbf) | ±2,220 N (500 lbf) | ±5 kN (1,125 lbf) |
| Max Axial Speed | 1,270 mm/m (50 in/min) | 1,000 mm/min (40 in/min) | 1,000 mm/min (40 in/min) |
| Max Frequency | 2 Hz | 2 Hz | 2 Hz |
| Torque Rating | ±10 Nm (87 lbf·in) | ±28 Nm (250 lbf·in) | ±20 Nm (177 lbf·in) |
| Max Angular Speed | 68 RPM | 10 RPM | 60 RPM |
| Frame Style | Horizontal | Vertical | Vertical |
| Applications | LuerTests ISO 594 | Biomedical | ASTM F543 & D7860 |
| Models | 530LE2 | 830LE3 | 830LE4 | 830LE5 | 830LE6 |
|---|---|---|---|---|---|
| Max Force Capacity | ±2.5 kN(550 lbf) | ±5 kN(1,125 lbf) | ±15 kN(3,375 lbf) | ±30 kN (6,750 lbf) | ±50 kN (11,250 lbf) |
| Max Axial Speed | 200 mm/s (8 in/s) | 125 mm/s (5 in/s) | 250 mm/s (10 in/s) | 100 mm/s (4 in/s) | 100 mm/s (4 in/s) |
| Max Frequency | 15 Hz | 15 Hz | 15 Hz | 15 Hz | 15 Hz |
| Static Torque Capacity | ±10 Nm (90 lbf·in) | ±25 Nm to 180 Nm(220 lbf·in to 1,600 lbf·in) | ±25 Nm to 180 Nm(220 lbf·into 1,600 lbf·in) | ±25 Nm to 180 Nm(220 lbf·into 1,600 lbf·in) | ±25 Nm to 180 Nm(220 lbf·into 1,600 lbf·in) |
| Frame Style | Compact Tabletop | Tabletop | Tabletop | Table or Floor Standing | Floor Standing |
| Model | 930LX100 | 930LX250 | 930LX500 |
|---|---|---|---|
| Type | Servohydraulic | Servohydraulic | Servohydraulic |
| Max Axial Force | 100 kN(22,500 lbf) | 250 kN (55,000 lbf) | 500 kN (112kip) |
| Dynamic Torque Rating | 1 kNm(9,000 lbf·in) | 1 kNm(9,000 lbf·in) | 2 kNm(18,000 lbf·in) |
