Planar Biaxial Test Machines

홈 > UTM > Planar Biaxial Test Machines

planar bixial test machnines series
Series Type ForceRanges Max Frequency
174 Series Electromechanical 10 kN to 200 kN(2,250 lbf to 45,000 lbf) 2 Hz
574 Series Electrodynamic 100 N to 5 kN(22 lbfto 1,125 lbf) 15 Hz
974 Series Servo Hydraulic 100 kNto 250 kN(22,500 lbfto 55,000 lbf) 30 Hz
174LA55
Model Force Rating Stroke (per actuator) Max Frequency
174LA55 ±250 N (55 lbf) 25 mm (50 mm per axis) 2 Hz
574
Model Force Speed
574 Six actuators rated from 2.6 kN to 55 kN (580 lbfto12,400 lbf) Test Frequencies up to 15 Hz.
974LX
Model Force Speed
974LX Actuators available from 50 kN (11,250 lbf) and higher forces Test Frequencies up to 50 Hz
